Dongfeng Cummins XCMG 12 Ton Telescopic Crane Truck With Tipping Box

Brand Name : CLW

Model Number : CLW5251WYSCD

Certification : ISO, CCC

Place of Origin : Suizhou,China

MOQ : 1 UNIT

Price : 18520 usd/unit~78660 usd/unit

Payment Terms : L/C, T/T, D/P, T/T, Western Union, MoneyGram, D/A

Supply Ability : 300units/month

Delivery Time : Within 30days after received advance payments

Packaging Details : Naked package shipped by bulk ship

Truck brand : Dongfeng Crane Truck

Driving model : LHD,RHD

Crane brand : XCMG,PALFINGER,CLW

Max. crane capacity : 12Ton

Crane type : Telescopic, Knult Arm Crane

Engine : Cummins or Yuchai Engine

Material : Q235 carbon steel

Max. Lifting height : 13.5meters

Working radius : 11.5meters

Turning angle : 360 °

Origin : Suizhou city,China

Contact Now

Dongfeng Cummins XCMG 12Ton Telescopic Crane Truck with Tipping Box


Description:

1. Crane Brand: Chinese Famous Brand
2. Heavy Duty Cargo box.
3. H Shape Hydraulic front & Rear Leg for safety.
4. Folded Arm & Telescopic Straight Arm Crane for option.
5. Crane capacity: 26.3ton,8ton,10ton,12ton, 14ton,16ton,20ton,25ton

Reference picture

Dongfeng Cummins XCMG 12 Ton Telescopic Crane Truck With Tipping Box

Dongfeng Cummins XCMG 12 Ton Telescopic Crane Truck With Tipping Box

Dongfeng Cummins XCMG 12 Ton Telescopic Crane Truck With Tipping BoxDongfeng Cummins XCMG 12 Ton Telescopic Crane Truck With Tipping Box

Dongfeng Cummins XCMG 12 Ton Telescopic Crane Truck With Tipping Box

Dongfeng Cummins XCMG 12 Ton Telescopic Crane Truck With Tipping Box

Specification

Product Specification

General Technical Parameters
Overall Dimension 12000×2500×3980 (mm)
Gross Vehicle Weight 24900(Kg)
Curb Weight 15800(Kg)
Chassis Specification
Chassis Brand Dongfeng
Drive model 6*2
Cabin Double, Left Hand Driving, with air conditional
Number of Passengers 3
Engine Model 4-stroke direct injection , 6-cylinder in-line with water cooling, inter-cooling, EGR
Power
161KW/220HP
Emission standard EURO 3
Displacement 6870(ml)
Fuel type Diesel
Gearbox 8Forwards & 1Reverse
Brake System Air break
Wheel Base 2100+5250 mm
Front/Rear Axle Loading 8000/11500(Kg)
Approach/Departure Angle 23/12(°)
Overhang 1250/3545(mm)
Tire 11.00R20
Max Driving Speed 90(km/h)
Upperstructure Specification
Cargo Body Dimension 2500×1880×380(mm)
Material Q235 carbon steel
Cargo Thickness Side 1.5mm, Bottom 2.5mm
Working System Boom Type Straight 3-Arm telescopic boom
Crane Crane Brand XCMG or SANY or CLW
Range of Sprayer 30m
Max Lifting Moment 25(T.M)
Max Lifting Capacity 10000(kg)
Max lifting height 12(m)
Rotation angle 360(°)
Installation space 1150(mm)
Recommented power 30(kw)
Maximum working pressure 26(Mpa)
Max Flow 63(l/min)
Crane weight 3800(kg)
Oil tank capacity 160(L)
Leg Leg type H type
Leg Span 2.28-5.9(m)
Hydraulic system Pressure 18(M pa)
Capacity 70(l)
Other Configuration Control system in 2 side; diamond palt, yellow warning fire; 2.5T arm, etc.
Options Caution light, air condition, inlet valve, medicine tray, pneumatic valve, cylinder, etc.


Model XCMG/CLW/PALFINGER
Max. Lifting Capacity KG 63000
Max. Lifting momen T.M 15.7
Lifting height M 11
Working radius M 9
Recommend power KW 20
Max. Oil Flow of Hydraulic System L/Min 40
Max. Pressure of Hydraulic System Mpa 20
Oil Tank capacity L 90
Crane weight KG 2102
Installation Space mm 900
Rotation Angle ° 360° All rotation
